Frame

AL 6061

Stem

AL, Fixed

Fork

ZOOM Suspension Fork

Saddle

Black leather surface

Head Set

NECO

Tyre

CST / KENDA

Rim

Double AL

Reflector

Reflector, transparent CPSC, BS

Hub

Bearing

Chain

KMC

Brake

Disc Brake Hydraulic / Mechanical

Handle Bar

ZOOM AL6061

Shifting Lever

SHIMANO 7/8/9/10s

Rear Derailleur

SHIMANO 7/8/9/10s

Free Wheel

SHIMANO 7/8/9/10s

Front Derailleur

N/A

Data On Motor

Mid Motor Brand

AQL / BAFANG / MOTINOVA

Voltage (V)

48V

Power (W)

750W / 1000W

Rear Hub Motor

BAFANG / SHENGYI

Voltage (V)

48V

Power (W)

750W/ 1000W

Battery

20AH  LG / EVE cells

Sensor

Speed Sensor  Optional:Torque Sensor

Display

LCD         Optional:TFT/LED

Max Speed (Km/h)

25km/h / 32km/h

Head light

Optional

Rear light

Optional

Main Cable

1T3

Charger

54.6V-3A, AC, DC 2.1*5.5 US standard (UL/CE)

Charging Time

6h~7h
